Magnification | . | 1.5x - 9x |
Field of view (FOV) m at 100m | . | 28 - 4.6 |
Objective diameter (mm) | Effective diameter | 44 |
Exit pupil diameter (mm) | Measurement of the pupillary ocular beam | 9.5 - 4.9 |
Eye Relief (inches) | From the last optical surface | 4 |
Eye relief (mm) | From the last optical surface | 97 |
cm travel value per click at 100m | 1 Click = x/100m | 1 |
Elevation range total (cm at 100m) | 100 | 400 |
Windage range total (cm at 100) | 100m | 400 |
Parallax compensation | Parallax free at x distance | 100 m |
Transmission Daylight | ISO 14490-5:2005 | 90% |
Height (inches) | Without covers | 1.88 |
Height (mm) | Without covers | 47.9 |
Width (inches) | Fully extended | 2.66 |
Width (mm) | Fully extended | 67.5 |
Length (inches) | At outside diameter | 13.2 |
Length (mm) | At outside diameter | 336 |
Tube diameter (mm) | Width of main tube | 30 |
Weight (ounces) | Without covers | 20.28 |
Weight (grams) | Without covers | 575 |
Mechanical outer diameter (objective mm) | Objective end of scope | 51.2 |
Mechanical outer diameter (ocular mm) | Ocular end of scope | 43.8 |
Reticle Option | . | G4i Drop, G4i Fiber |
Accessories included with the purchase | . | Instruction manual, cleaning cloth, bikini scope cover, battery CR2032, throw lever |
